Product Description
Single Shaft Concrete Mixer
Technical Data
| Model | SSM350 |
| Plant Capacity (m3/h) | 17~21 |
| Output per Batch (L) | 350 |
| Capacity (L) | 560 |
| Max. Aggregate Size (mm) | 40/60 |
| Speed of Mixing (r/min) | 28 |
| Cycling Period (s) | 60 |
| Power of Mixing Motor (kw) | 15 |
| Power of Lifting Motor (kw) | 4 |
| Power of Water Pump (kw) | 0.75 |
| Hydraulic System Pressure (Mpa) | 12~16 |
| Speed of Lifting (m/min) | 20 |
| Dimension (mm) | 2528X2600X2850 |
| Overall Weight (kg) | 3360 |
